Rincian Produk
Tempat asal: Cina
Nama merek: Victory
Sertifikasi: ISO9001 ROHS
Nomor model: Inkonel 718
Dokumen: Brosur Produk PDF
Ketentuan Pembayaran & Pengiriman
Kuantitas min Order: 30 kg
Harga: negotiable
Kemasan rincian: Kotak karton kumparan, paket kumparan dengan polybag, kemudian dalam kotak kayu
Waktu pengiriman: 20 ~ 40 hari
Syarat-syarat pembayaran: L/C, T/T, Western Union, MoneyGram
Menyediakan kemampuan: 300 ton per bulan
Name: |
Nickel-Chromium-Columbium (Niobium)-Molybdenum nickel alloy inconel 718 wire rod bar for aerospace |
Material: |
Nickel Chromium Iron |
Ni (Min): |
50~55% |
Density: |
8.24 g/cm3 |
Melting point: |
1260-1320°C |
Elongation (≥ %): |
25 % |
Thermal conductivity: |
15.9 W/m·K |
Finishing: |
Bright,Oxided, acid white |
Application: |
Construction, Industry Oil, piping systems |
Yield strength: |
550MPa |
Tensile strength: |
910 MPa |
Hardness: |
≤ 363 HB |
Standard: |
ASTM, ASME |
size: |
6~200mm |
shape: |
Round, Square, flat |
Name: |
Nickel-Chromium-Columbium (Niobium)-Molybdenum nickel alloy inconel 718 wire rod bar for aerospace |
Material: |
Nickel Chromium Iron |
Ni (Min): |
50~55% |
Density: |
8.24 g/cm3 |
Melting point: |
1260-1320°C |
Elongation (≥ %): |
25 % |
Thermal conductivity: |
15.9 W/m·K |
Finishing: |
Bright,Oxided, acid white |
Application: |
Construction, Industry Oil, piping systems |
Yield strength: |
550MPa |
Tensile strength: |
910 MPa |
Hardness: |
≤ 363 HB |
Standard: |
ASTM, ASME |
size: |
6~200mm |
shape: |
Round, Square, flat |
Inconel 718 paduan
Inconel 718 adalah material serbaguna dan berkinerja tinggi yang cocok untuk aplikasi yang menuntut di berbagai industri.Sifat unik mereka membuat mereka ideal untuk digunakan di lingkungan di mana kekuatan, ketahanan korosi, dan stabilitas suhu tinggi sangat penting
Aplikasi batang Inconel 718:
Batang Inconel 718 digunakan dalam berbagai aplikasi yang menuntut karena kekuatan yang luar biasa, ketahanan korosi, dan kemampuan untuk bekerja pada suhu tinggi.Aplikasi umum meliputi:
Pesawat ruang angkasa:
Komponen mesin jet (misalnya, bilah turbin, segel, dan casing).
Bagian struktural di pesawat terbang yang membutuhkan rasio kekuatan berat tinggi.
Minyak dan Gas:
Alat dan peralatan lubang bawah yang digunakan dalam operasi pengeboran.
Katup, pompa, dan tabung yang beroperasi di lingkungan korosif.
Industri Nuklir:
Komponen untuk reaktor dan sistem lain yang harus tahan radiasi dan kondisi ekstrem.
Turbin gas:
Bagian yang membutuhkan ketahanan suhu tinggi, seperti ruang pembakaran dan komponen turbin.
Perangkat medis:
Instrumen bedah dan implan di mana ketahanan korosi dan kekuatan sangat penting.
Peralatan Industri:
Digunakan dalam berbagai mesin dan komponen yang terkena tekanan tinggi dan lingkungan korosif.
Aplikasi Laut:
Komponen yang harus tahan korosi air laut, seperti pengikat dan fittings.
Mobil:
Komponen mesin berkinerja tinggi yang membutuhkan daya tahan dan ketahanan panas.
Sifat Kimia Inconel 718
Nikel (ditambah Kobalt)50.00-55.00
Kromium....................................................................................................................................................................................................................................17.00-21.00
Besi.......................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
Niobium (ditambah Tantalum)4.75-5.50
Molibdenum........................................................................................................................... yang dapat digunakan sebagai bahan baku untuk pembuatan bahan baku2.80-3.30
Titanium............................................................................................................................................................................................................................................................0.65-1.15
Aluminium..................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................0.20-0.80
Kobalt.......................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................1.00 maksimal.
Karbon0.08 maksimal.
Mangan.......................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................0.35 maksimal.
Silikon0.35 maksimal.
Fosfor............................................................................................................................................................................................................................................................0.015 maksimal.
Sulfur.......................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................0.015 maksimal.
Boron.......................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................0.006 maksimal.
Tembaga0.30 maksimal
| Kepadatan | 8.19g/cm3 | 0.296 lb/in3 |
| Titik leleh | 1260-1336 | 2437°F |
Seri Inconel
Sesuaikan ukuran seperti di bawah ini
|
Bentuk
|
Ukuran ((mm)
|
|
Kami akan
|
0.5-7.5
|
|
Rod/Bar
|
8.0-200
|
|
Strip
|
(0.5-2.5) * ((5-180)
|
|
Tabung
|
dibuat khusus
|
|
Piring
|
dibuat khusus
|
Hubungi kami
Email: victory@dlx-alloy.com
Layanan OEM:
Selamat datang ukuran khusus
Kami adalah pabrik pengalaman untuk layanan OEM & ODM
