Changzhou Victory Technology Co., Ltd victory@dlx-alloy.com 86-199-06119641
Rincian Produk
Tempat asal: Cina
Nama merek: Victory
Sertifikasi: ISO9001 ROHS
Nomor model: Inkonel 718
Dokumen: Brosur Produk PDF
Ketentuan Pembayaran & Pengiriman
Kuantitas min Order: 30 kg
Harga: negotiable
Kemasan rincian: Kotak karton kumparan, paket kumparan dengan polybag, kemudian dalam kotak kayu
Waktu pengiriman: 20 ~ 40 hari
Syarat-syarat pembayaran: L/C, T/T, Western Union, MoneyGram
Menyediakan kemampuan: 300 ton per bulan
Name: |
Polished black surface OD 50mm 70mm 80mm 120mm nickel alloy bar inconel 718 round bar for aircraft engines |
Material: |
Nickel Chromium Iron |
Ni (Min): |
50~55% |
Density: |
8.24 g/cm3 |
Melting point: |
1260-1320°C |
Elongation (≥ %): |
25 % |
Thermal conductivity: |
15.9 W/m·K |
Finishing: |
Bright,Oxided, acid white |
Application: |
Construction, Industry Oil, piping systems |
Yield strength: |
550MPa |
Tensile strength: |
910 MPa |
Hardness: |
≤ 363 HB |
Standard: |
ASTM, ASME |
size: |
6~200mm |
shape: |
Round, Square, flat |
Name: |
Polished black surface OD 50mm 70mm 80mm 120mm nickel alloy bar inconel 718 round bar for aircraft engines |
Material: |
Nickel Chromium Iron |
Ni (Min): |
50~55% |
Density: |
8.24 g/cm3 |
Melting point: |
1260-1320°C |
Elongation (≥ %): |
25 % |
Thermal conductivity: |
15.9 W/m·K |
Finishing: |
Bright,Oxided, acid white |
Application: |
Construction, Industry Oil, piping systems |
Yield strength: |
550MPa |
Tensile strength: |
910 MPa |
Hardness: |
≤ 363 HB |
Standard: |
ASTM, ASME |
size: |
6~200mm |
shape: |
Round, Square, flat |
Inconel 718 paduan
Paduan INCONEL 718 memiliki ketahanan korosi yang sangat baik terhadap banyak media.Nikel berkontribusi terhadap ketahanan korosi dalam banyak zat anorganik dan organik, selain sangat mengoksidasi, senyawa di berbagai kisaran keasaman dan kealkalian.
Sifat dan sifat mekanik utama yang menjadikan Inconel 718 paduan berkinerja tinggi
Inconel 718 diakui sebagai paduan berkinerja tinggi karena sifat mekanik dan karakteristiknya yang luar biasa.
Sifat Mekanis Utama
Kekuatan hasil tinggi:
Menjaga kekuatan hasil tinggi (hingga 1.200 MPa atau lebih) pada suhu kamar dan suhu tinggi, membuatnya cocok untuk aplikasi tekanan tinggi.
Kekuatan tarik:
Menampilkan ketahanan tarik yang sangat baik (hingga 1.400 MPa) yang penting untuk komponen yang mengalami beban berat.
Ketahanan kelelahan:
Ketahanan yang luar biasa terhadap kegagalan kelelahan, memungkinkan untuk menahan beban siklik tanpa degradasi yang signifikan dari waktu ke waktu.
Duktilitas:
Duktilitas yang baik memastikan bahwa material dapat berubah bentuk tanpa retak, yang sangat penting untuk aplikasi yang membutuhkan ketahanan di bawah tekanan.
Ketangguhan Dampak:
Menjaga ketahanan bahkan pada suhu rendah, membuatnya cocok untuk aplikasi di mana ketahanan dampak sangat penting.
Resistensi merangkak:
Ketahanan yang sangat baik terhadap deformasi merangkak pada suhu tinggi, yang sangat penting untuk komponen yang beroperasi dalam lingkungan suhu tinggi.
Sifat Kimia Inconel 718
Nikel (ditambah Kobalt)50.00-55.00
Kromium....................................................................................................................................................................................................................................17.00-21.00
Besi.......................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
Niobium (ditambah Tantalum)4.75-5.50
Molibdenum........................................................................................................................... yang dapat digunakan sebagai bahan baku untuk pembuatan bahan baku2.80-3.30
Titanium............................................................................................................................................................................................................................................................0.65-1.15
Aluminium..................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................0.20-0.80
Kobalt.......................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................1.00 maksimal.
Karbon0.08 maksimal.
Mangan.......................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................0.35 maksimal.
Silikon0.35 maksimal.
Fosfor............................................................................................................................................................................................................................................................0.015 maksimal.
Sulfur.......................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................0.015 maksimal.
Boron.......................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................0.006 maksimal.
Tembaga0.30 maksimal
| Kepadatan | 8.19g/cm3 | 0.296 lb/in3 |
| Titik leleh | 1260-1336 | 2437°F |
Seri Inconel
Sesuaikan ukuran seperti di bawah ini
|
Bentuk
|
Ukuran ((mm)
|
|
Kami akan
|
0.5-7.5
|
|
Rod/Bar
|
8.0-200
|
|
Strip
|
(0.5-2.5) * ((5-180)
|
|
Tabung
|
dibuat khusus
|
|
Piring
|
dibuat khusus
|
Hubungi kami
Email: victory@dlx-alloy.com
Layanan OEM:
Selamat datang ukuran khusus
Kami adalah pabrik pengalaman untuk layanan OEM & ODM
